CNC & Laser Gear Generator for Woodworking Projects
Design laser-ready and CNC-ready gears, gear trains, mounting plates, and test cut sheets in SVG and DXF.
Features
Built for practical gear files, not just pretty previews.
CutGear Studio focuses on the geometry and export details that matter when a design moves from screen to laser bed or CNC table.
SVG & DXF export
1–5 gear trains
2D line preview
3D preview
Mounting plate templates
Test cut sheets
Red / blue / green laser-ready line colors
CNC and laser-ready workflow
Who It Is For
For makers who need useful SVG and DXF output.
Whether the design starts with gear size, axle distance, or a mounting plate, the studio keeps the workflow close to real fabrication.
Workflow
From first dimensions to cut-ready files.
A simple four-step process keeps the design loop fast while preserving access to advanced controls when you need them.
Choose gear size or axle distance
Preview gears in 2D or 3D
Add mounting plate or test sheet
Export SVG or DXF
Export Color System
Color-coded for laser and CNC workflows.
Universal SVG and DXF colors keep cut geometry, holes, and reference/engraving geometry separated for tools like CorelDRAW, LightBurn, Illustrator, and Inkscape.
Red
outside cuts
Blue
inside cuts / holes
Green
guides / engraving
MVP / Beta
CutGear Studio is currently in MVP/beta testing.
A paid subscription version is planned later.
Try the Studio
